IQF FREEZER
Fluidized IQF (Individual Quick Freezing) freezer is a specialized equipment designed for rapidly freezing food products while maintaining their individual quality. It incorporates advanced quick-freezing technology and new design concepts, utilizing fluidized freezing techniques. With its stainless steel conveyor belt and mesh belt configuration, the freezer blows cold air upward, effectively freezing the products in a suspended state. This results in quick and even freezing, with the surface and deep layers of the product frozen simultaneously, thus achieving superior monomer frozen goods.
Quick Freezer Equipment Flow
Fresh Products — Loading — Rapid Freezing — Cold Air Circulation — Exit at -18°C
The quick freezer rapidly reduces the core temperature of food items to -18°C, efficiently passing through the critical ice crystal formation zone (0°C to -5°C) within 30 minutes. This process locks in nutrients and maintains the original texture and flavor of the product. It is ideal for a wide range of products such as meat, seafood, vegetables, prepared meals, and dairy. Available in fluidized, tunnel, and spiral configurations, the quick freezer provides flexible, high-capacity, and energy-efficient freezing solutions.
Quick Freezer Equipment Features
Rapid Freezing Efficiency: Reduces core product temperature to -18°C quickly while preserving food structure and nutrition.
Versatile Applications: Suitable for freezing various food types including meat, fish, shrimp, vegetables, and dairy in different shapes and sizes.
Multiple Freezer Types: Available as fluidized, tunnel, and spiral quick freezers to meet different process needs.
Adjustable Freezing Time: Variable frequency control allows freezing times between 4–40 minutes, adaptable for different products.
Energy Efficient & Reliable: Uses modern refrigerants (R22, R404A, R717) and optimized cold consumption for cost-effective freezing.
| Model | GLZ-0.5 | GLZ-1.0 | GLZ-1.5 | GLZ-2.0 | GLZ-3.0 |
|---|---|---|---|---|---|
| Capacity (kg/h) | 500 | 1000 | 1500 | 2000 | 3000 |
| Overall Dimensions (m) | 7.0 × 3.8 × 4.05 | 8.0 × 4.5 × 4.05 | 10.0 × 4.5 × 4.05 | 11.04 × 4.5 × 4.05 | 14.5 × 4.5 × 4.05 |
| Freezing Room Length (m) | 5.0 | 6.0 | 8.0 | 9.0 | 12.5 |
| Inlet Temperature (°C) | +15 | ||||
| Outlet Temperature (°C) | -18 | ||||
| Freezing Temperature (°C) | ≤ -33 | ||||
| Freezing Time (min) | 4–40 (Variable Frequency) | ||||
| Refrigerant | R22 / R404A / R717 | ||||
| Cold Consumption (kW) | 95 | 165 | 245 | 325 | 490 |
| Installed Power (kW) | 30.9 | 46.3 | 61.4 | 74.2 | 101.7 |
Accessories
